Bảng thông số chung
| Servo Drive | Model | Power (W) |
Voltage (VAC) |
Dimensions (mm) |
Weight (kg) |
| AC Servo Drive EL8 Series | EL8-EC400F | 400 | 1 Phase/ 3 Phase 220 |
150*150*43 | 1 |
| EL8-RS400F | |||||
| EL8-EC750F | 750 | 150*160*55 | 1.2 | ||
| EL8-RS750F | |||||
| EL8-EC1000F | 1000 | ||||
| EL8-RS1000F | |||||
| EL8-EC1500F | 1500 | 183*168*80 | 2 | ||
| EL8-RS1500F | |||||
| EL8-EC2000F | 2000 | ||||
| EL8-RS2000F | |||||
| AC Servo Drive EL7 Series – 220VAC |
EL7-RS400P | 400 | 1 Phase 220 | 175*156*40 | 0.9 |
| EL7-RS750P | 750 | 175*156*50 | 1.1 | ||
| EL7-RS1000P | 1000 | ||||
| EL7-RS1500P | 1500 | 1 Phase/ 3 Phase 220 |
175*156*80 | 2.3 | |
| EL7-RS2000P | 2000 | ||||
| AC Servo Drive EL7 Series – 400VAC |
EL7-RS750PT | 750 | 3 Phase 400 | 179*175*55 | 1.3 |
| EL7-RS1000PT | 1000 | ||||
| EL7-RS1500PT | 1500 | 179*175*80 | 1.9 | ||
| EL7-RS2000PT | 2000 | ||||
| EL7-RS3000PT | 3000 | ||||
| EL7-RS4400PT | 4400 | 230*250*90 | 3.3 | ||
| EL7-RS5500PT | 5500 | ||||
| EL7-RS7500PT | 7500 | ||||
| EL7-RS11K0T | 11000 | 280*170*180 | |||
| EL7-RS15K0T | 15000 | ||||
| EL7-RS18K5T | 18500 | ||||
| EL7-RS22K0T | 22000 | ||||
| AC Servo Drive EL7 Series – 220VAC |
EL7-EC400N | 400 | 1 Phase 220 | 175*156*40 | 0.9 |
| EL7-EC750N | 750 | 175*156*50 | 1.2 | ||
| EL7-EC1000N | 1000 | ||||
| EL7-EC1500N | 1500 | 1 Phase/ 3 Phase 220 |
179*175*55 | 2.3 | |
| EL7-EC2000N | 2000 | ||||
| 4EL7-ECA05 | 400 | 230*200*90 | |||
| 4EL7-ECA05 | 400 | ||||
| 400 | |||||
| 750 | |||||
| 1000 | |||||
| 4EL7-ECA07 | 1000 | ||||
| 1000 | |||||
| 750 | |||||
| AC Servo Drive EL7 Series – 400VAC |
750 | 3 Phase 400 | 179*175*55 | 1.3 | |
| EL7-EC1000NT | 1000 | ||||
| EL7-EC1500NT | 1500 | 179*175*80 | 1.9 | ||
| EL7-EC2000NT | 2000 | ||||
| EL7-EC3000NT | 3000 | ||||
| EL7-EC4400NT | 4400 | 230*250*90 | 3.3 | ||
| EL7-EC5500NT | 5500 | ||||
| EL7-EC7500NT | 7500 | ||||
| EL7-EC11K0T | 11000 | 280*170*180 | |||
| EL7-EC15K0T | 15000 | ||||
| EL7-EC18K5T | 18500 | ||||
| EL7-EC22K0T | 22000 | ||||
| AC Servo Drive EL6 Series – 200VAC |
EL6-RS400P | 400 | 1 Phase 220 | 175*156*40 | 0.9 |
| EL6-CAN400Z | |||||
| EL6-RS750P | 750 | 175*156*50 | 1.1 | ||
| EL6-CAN750Z | |||||
| EL6-RS1000P | 1000 | 175*156*50 | 1.2 | ||
| EL6-CAN1000Z | |||||
| EL6-EC400 | 400 | 175*156*40 | |||
| EL6-EC750 | 750 | 175*156*50 | |||
| EL6-EC1000 | 1000 | 175*156*50 | |||
| EL6-EC1500 | 1500 | ||||
| EL6-EC2000 | 2000 | 175*179*80 | |||
| 2EL6-EC400 | 400 | 168*154*48 | |||
| 2EL6-EC750 | 750 | 168*154*55 | |||
| 2EL6-EC1000 | 1000 | 1 Phase/ 3 Phase 220 |
168*183*55 | ||
| 2EL6-EC1500 | 1500 | 168*183*75 |
