ELVM M17
| Type Name ELVM Series | Matched Drive | Matched Cable | ||||
| CANopen | RS485 | Motor Cable | Motor +Brake Cable | Encoder Cable | Brake Cable | |
| 4005V48EH-M17-HD | ELD2-CAN7005B | ELD2-RS7005 | / | CABLE-RZSD*M*-123 | CABLE-BMAD*M*-223 (Multi-turn) |
/ |
| 4005V48FH-M17-HD | CABLE-RZD*M*-123 | / | ||||
| 4010V48EH-M17-HD | / | CABLE-RZSD*M*-123 | ||||
| 4010V48FH-M17-HD | CABLE-RZD*M*-123 | / | ||||
| 6020V24EH-M17-HD | ELD2-CAN7010B | ELD2-RS7010 | CABLE-RZD*M*-143 | / | CABLE-SCD*M*-113 | |
| 6020V24FH-M17-HD | / | / | ||||
| 6020V48EH-M17-HD | CABLE-RZD*M*-123 | / | CABLE-SCD*M*-113 | |||
| 6020V48FH-M17-HD | / | / | ||||
| 6040V24EH-M17-HD | ELD2-CAN7020B 2ELD2-CAN7020B |
ELD2-RS7020B 2ELD2-RS7020B |
CABLE-RZD*M*-253 | / | — — — — | CABLE-SCD*M*-113 |
| 6040V24FH-M17-HD | / | / | ||||
| 6040V48EH-M17-HD | ELD2-CAN7010B | ELD2-RS7010 | CABLE-RZD*M*-143 | / | CABLE-BMD*M*-213 (Single-turn) |
CABLE-SCD*M*-113 |
| 6040V48FH-M17-HD | / | / | ||||
| 6060V48EH-M17-HD | ELD2-CAN7015B | ELD2-RS7015B | CABLE-RZD*M*-253 | / | CABLE-SCD*M*-113 | |
| 6060V48FH-M17-HD | / | / | ||||
| 8075V48EH-M17-HD | ELD2-CAN7020B 2ELD2-CAN7020B |
ELD2-RS7020B 2ELD2-RS7020B |
/ | CABLE-SCD*M*-113 | ||
| 8075V48FH-M17-HD | / | / | ||||
| 80100V48EH-M17-HD | ELD2-CAN7030B 2ELD2-CAN7030B |
ELD2-RS7030B 2ELD2-RS7030B |
CABLE-RZD*M*-263 | / | CABLE-SCD*M*-113 | |
| 80100V48FH-M17-HD | / | / | ||||
| 130120V48EM-M17-HD | ELD2-CAN7040B | ELD2-RS7040B | CABLE-RZSD*M*-282 | CABLE-BMAD*M*-222 (Multi-turn) |
||
| 130120V48FM-M17-HD | ||||||
| 130150V48EM-M17-HD | — — — — | |||||
| 130150V48FM-M17-HD | ||||||
| 130200V48EM-M17-HD | ELD2-CAN7060B | ELD2-RS7060B | CABLE-BMD*M*-212 (Single-turn) |
|||
| 130200V48FM-M17-HD | ||||||
ELVM B25
| Type Name ELVM Series | Matched Drive | Matched Cable | ||||
| CANopen | RS485 | Motor Cable | Motor +Brake Cable | Encoder Cable | Brake Cable | |
| 4005V48EH-B25-HD | ELD2-CAN7005B | ELD2-RS7005 | / | CABLE-RZSD*M*-123 | CABLE-LD2-BM*M* (Single-turn) |
/ |
| 4005V48FH-B25-HD | CABLE-RZD*M*-123 | / | ||||
| 4010V48EH-B25-HD | / | CABLE-RZSD*M*-123 | ||||
| 4010V48FH-B25-HD | CABLE-RZD*M*-123 | / | ||||
| 6020V24EH-B25-HD | ELD2-CAN7010B | ELD2-RS7010 | CABLE-RZD*M*-143 | / | CABLE-SCD*M*-113 | |
| 6020V24FH-B25-HD | / | / | ||||
| 6020V48EH-B25-HD | CABLE-RZD*M*-123 | / | CABLE-SCD*M*-113 | |||
| 6020V48FH-B25-HD | / | / | ||||
| 6040V24EH-B25-HD | ELD2-CAN7020B 2ELD2-CAN7020B |
ELD2-RS7020B 2ELD2-RS7020B |
CABLE-RZD*M*-253 | / | CABLE-SCD*M*-113 | |
| 6040V24FH-B25-HD | / | / | ||||
| 6040V48EH-B25-HD | ELD2-CAN7010B | ELD2-RS7010 | CABLE-RZD*M*-143 | / | CABLE-SCD*M*-113 | |
| 6040V48FH-B25-HD | / | / | ||||
| 6060V48EH-B25-HD | ELD2-CAN7015B | ELD2-RS7015B | CABLE-RZD*M*-253 | / | CABLE-SCD*M*-113 | |
| 6060V48FH-B25-HD | / | / | ||||
| 8075V48EH-B25-HD | ELD2-CAN7020B 2ELD2-CAN7020B |
ELD2-RS7020B 2ELD2-RS7020B |
/ | CABLE-SCD*M*-113 | ||
| 8075V48FH-B25-HD | / | / | ||||
| 80100V48EH-B25-HD | ELD2-CAN7030B 2ELD2-CAN7030B |
ELD2-RS7030B 2ELD2-RS7030B |
CABLE-RZD*M*-263 | / | CABLE-SCD*M*-113 | |
| 80100V48FH-B25-HD | / | / | ||||
